Rear axle set - brake discs + Xtreme Performance brake pads (2x DBA42809S + DB15006XP) - DBA Brakes
Availability for pickups could not be loaded
- Ideal for lively riding with a 12-month manufacturer's warranty
- HHigh quality, high performance for your specific requirements
- One package contains 1 set per axle
DBA recommends T3-Slot brake discs from the 4000 and 5000 series to achieve optimum braking performance.
Specifications:
- Suitable for the road and occasionally for the race track
- Perfectly matched combination of brake disc and brake pad
- Save 5% of the price when you buy a combo
- DBA brake disks: Kangaroo Paw ventilation system with 144 diamond and drop-shaped blades
- DBA brake discs: T3 slots - increased number of exit points; through which brake pad dust and gases can escape, ensuring even and effective friction at every brake stop
- DBA brake disks: Thermal Stability Treatment (TSP) and improved durability of the brake disk under heavy braking conditions
- DBA brake pads: Semi-metallic carbon fiber friction material
- DBA brake pads: G-G class friction (average coefficient of friction of 0.45µ at low to high temperatures)
- DBA brake pads: Outstanding performance at high temperatures
- DBA brake pads: Optimum braking consistency up to 550℃ (1022℉)
- Direct replacement, no modifications to the vehicle necessary
- One combo - one manufacturer = no warranty problems
Contents of the kit DBA42809S-15006XP
- 2 x DBA42809S - 4000 series - T3
- 1 x DB15006XP - Brake pads Xtreme Performance ECE R90 certified | Rear axle
Technical information Brake disk:
- Diameter [mm]: 310
- Windshield ventilation: Kangaroo Paw
- Number of holes: 5
- Inner diameter [mm]: 65
- Minimum thickness [mm]: 20
- Thickness [mm]: 22
- Height [mm]: 48.5
- Stage: Stage 4
- Technical Bulletins: Bedding in Brakes
- Technical Bulletins: How to clean a Disc Rotor before fitting
- Technical Bulletins: Motorsport - Important Info
- ECE R90 number: E11*90R02/06*60524*00
- Total weight [kg]: 7.11
Technical information Brake disk:
- Width [mm]: 123
- Height [mm]:I: 61.3;O:56.4
- Thickness of the brake pad [mm]: 15.2
- FMSI:
- OEM: 8V0698451G
- Axle: Rear
- ECE R90 number: E11 R90-02A01584/53223
- Total weight [kg]: 1.24
Compatible vehicles:
| Brand | Model | Year of construction | variant | Category |
|---|---|---|---|---|
| AUDI | RS3 8V | 2015-2016 | 2.5 Turbo 362BHP (2015-2016) | Rear |
| AUDI | RS3 8V | 2017-2020 | 2.5 Turbo 400BHP Hatchback (2017-2020) | Rear |
| AUDI | RS3 8V | 2017-2020 | 2.5 Turbo 400BHP Sedan (2017-2020) | Rear |
| AUDI | RS3 8Y | 2021-2024 | 2.5 Turbo 400BHP (2021-2024) | Rear |
| AUDI | RS3 8Y | 2025- | 2.5 Turbo 400BHP (2025-) | Rear |
| AUDI | RSQ3 F3 | 2019- | 2.5 Turbo 400BHP (2019-) | Rear |
| AUDI | TTRS quattro 8S | 2016- | 2.5 Turbo 400BHP (2016-) | Rear |
